ULNA 2516 Amplifier 0,05 bis 2,6 GHz FM&DAB Notch

Product No.:
10131
1 Week 1 Week (abroad may vary)
59,00 EUR

incl. 19% tax excl. Shipping costs

Add to wish list
Ask about product
Description
Broadband Low Noise Amplifier 0,05 to 2,6 GHz
Excellent, e.g. as a preamplifier for broadband aplicationes in test setups. Its flat amplitude frequency response is constant over a wide frequency range. The compact size makes it easy to integrate and useful in many applications.

Specifications
  • Frequency range: 80-2600 MHz
  • Gain: 16 dB to 1,8 GHz
  • Max output level: 13dBm to 1,8 GHz
  • Input return loss:-26dB min
  • Output return loss:-20 dB min
  • Noise figure: <1.9 dB
  • IP3: 24dBm
  • Connector:  FEMALE - SMA male
  • Impedance 50 ohm
  • Current consumption: 8-18 V 80mA Power supply: direct and remote power.
  • DC jack 2.5 mm
  • Dimensions: 62X28X18 mm without connectors
